PULSE OXIMETER
CMS50DL1
Features
- Small in size
- Easy to operate
- Low power consumption
- Light in weight
- Convenient to carry
Specifications
| SpO2(*1) | Display range | 0 % SpO2 ~ 99 % SpO2 |
|---|---|---|
| Measured range | 0 % SpO2 ~ 100 % SpO2 | |
| Accuracy (*2) | 70 % SpO2 ~ 100 % SpO2 : ±2% SpO2; 0% SpO2 ~ 69 % SpO2 : unspecified |
|
| Resolution | 1 % SpO2 | |
| Plus rate | Display range | 30 bpm ~ 250 bpm |
| Measured range | 30 bpm ~ 250 bpm | |
| Accuracy (*3) | ±2 bpm or ±2%, whichever is greater | |
| Resolution | 1 bpm | |
| Battery | 1.5V (AAA (LR03)size) alkaline batteries x 2 | |
| Battery life | Two batteries can work continually for 24 hours | |
| Dimensions | Approx. W36 ×H32 ×D61 mm | |
| Weight | Approx. 60g (including batteries) | |
- *1The claims of SpO2 accuracy shall be supported by clinical study measurements taken over the full range. By artificial inducing, get the stable oxygen level to the range of 70 % to 100 % SpO2, compare the SpO2 values collected by the secondary standard pulse oximeter equipment and the tested equipment at the same time, to form paired data, which are used for the accuracy analysis.
There are 12 healthy volunteers (male: 6. female: 6; age: 18~45; skin color: black: 2, light: 8, white: 2) data in the clinical report. - *2Because pulse oximeter equipment measurements are statistically distributed, only about two-thirds of pulse oximeter equipment measurements can be expected to fall within ±Arms of the value measured by a CO-OXIMETER.
- *3Patient simulator has been used to verify the pulse rate accuracy, it is stated as the root-mean-square difference between the PR measurement value and the value set by simulator.
