JM98910 |
JN98909 |
PPN10004S |
|
|---|---|---|---|
| Model Number | JM98910 | JN98909 | PPN10004S |
| Compatible Models | CL-S521/531/621/631 CL-S400DT |
CL-S700/703 | CL-E720/730 |
| Backing Paper Width | 25.4 to 118mm (1 to 4.65 inches) | ||
| Label Length | 25.4 to 120mm (1 to 4.72 inches) * Labels: Uncoated paper, t=0.09 (includes adhesive layer), for inner winding roll |
||
| Label Minimum Width | The label should be 16 to 22mm (0.63 to 0.87 inches) from the left edge of the backing paper (when viewed from in front of the paper output) | ||
| Maximum Label Width | Narrower than the backing paper | ||
| Label Thickness | 0.17mm (0.0067 inch) or less | ||
| Backing Paper Thickness | 0.07mm (0.0027 inch) or less | ||
| Maximum Diameter of Paper Roll | 203mm (8 inches) | ||
| Inner Diameter of Paper Roll | 76mm (3 inches) or more | ||
| Reliability | 100km or more (for the paper specifications listed above) | ||
| Peeling Location Accuracy | ±1.0mm | ||
